| Mechanical limit swith with positively-actuated NC r | |
| Metal housing and roller plunger | |
| 1NO + 1NC, snap action contacts | |
| IP67 | |
| -40°C to +70°C | |
| PVC black Ø 7,3 mm, 5 x 0,75 mm² | |
| -25°C to +70°C | |
| -40°C to +105°C (only available on request) | |
| Max. 240V AC / 1.5A Max. 250V DC / 0.1A | |
| 5 million switching operations at 240V DC/3W 1 million switching operations at 230V AC/0,5A | |
| 0.2 kg | |
| 0.45 kg |
Please note:
The limit switches can be mounted on all four sides of the cylinder tube. However, the limit switch position is always offset by 90° from the lubrication position. (See PDF.)
The ZIMM Limit switch ES for actuators is manufactured at the headquarters of ZIMM GmbH in Lustenau. Its development and manufacture are part of the ISO 9001:2015-certified processes for accessories and components.
