ZIMM production according to drawing | Gear cutting from module 0.3 to 12 for spur gears, bevel gears and worms
| Manufacturing services: | Gear cutting · Grinding · Thread production · Heat treatment · Surface protection · Test reports |
| Components: | Spur gears · Bevel gears · Worms · Worm gears · Ball screws · Trapezoidal screws · Nuts |
| Gear cutting: | Module 0.3 to 12 | Spur gears, straight and helical – up to Ø 1500 mm · Bevel gears, straight and helical – up to Ø 1000 mm · Bevel gears, spiral toothed – up to Ø 500 mm · Single and multi-start worms – up to Ø 500 mm · Worm gears – up to Ø 1000 mm |
| Threads: | Ball screws and nuts – 16×5 to 160×80 · Trapezoidal screws and nuts – 12×3 to 160×20 |
| Material: | Steel · Aluminium · Bronze · Plastic · Others on request |
| Prototypes & Series: | Prototype · Small series · Medium series |
| Quality management: | ISO 9001:2015 · Open to further standards, assessed project-specifically |
ZIMM manufactures drive elements to customer drawings: spur gears, straight and helical bevel gears, spiral toothed bevel gears, single and multi-start worms and worm gears, as well as ball and trapezoidal screws including the corresponding nuts. Production takes place as a prototype, a small series or a medium series. Which processes, materials and test scopes are suitable results from the geometry, the tolerance specifications and the quantity of the respective component. ZIMM assesses this information and supports process selection and production planning. Design, material selection, tolerance and quality specifications are defined in the drawing submitted.
ZIMM GmbH develops and manufactures screw jacks, bevel gearboxes, electromechanical actuators and matching add-on parts for industrial lifting, positioning and drive tasks at Millenniumpark 3, 6890 Lustenau, Austria. Production according to drawing is part of the ISO 9001:2015 certified processes at that location.
Our service overview
At ZIMM, we understand that the quality of every machine depends on the details of its components. That’s why we offer you a comprehensive range of manufacturing services that are perfectly tailored to your requirements.
Benefit from ZIMM's customised production, which combines the finest gear cutting and grinding techniques as well as robust heat treatments with precise testing procedures to ensure the quality and precision of your drive components. Enquire now and define new standards.
We offer a wide range of gear cutting options to meet your exacting specifications.
- Worm gears | up to Ø 1000 mm
- Modul 0,3 – 12
- Spur gears, straight and helical | up to Ø 1500 mm
- Bevel gears, straight and helical | up to Ø 1000 mm
- Bevel gears, spiral toothed | up to Ø 500 mm
- Single and multi-start worms | up to Ø 500 mm
Perfect the surfaces of your components with ZIMM: Precise grinding for spur gears, threads and more.
- Spur gears, straight and helical gears
- Worms and ball screws
- Internal and external cylindrical grinding
- Surface grinding
- Centre grinding
Discover the perfect thread with matching nuts – whether for simple adjustment tasks or high duty cycles and speeds – to suit your specifications.
- Ball screws and nuts | 16×5 – 160×80
- Trapezoidal screws and nuts | 12×3 – 160×20
Depending on your requirements, we offer your customised drive elements in various materials.
- Various steel versions
- Aluminium
- Bronze
- Plastic
- Others on request
Customised production solutions for prototypes as well as small and medium-volume series production.
- Prototype construction: Fast, precise implementation of your development samples.
- Small series: Cost-effective production of special components in small batch sizes.
- Medium series: Consistent quality and reliable delivery for your ongoing requirements.
Increase the service life and performance of your components with our specialised heat treatment and surface protection processes.
- Annealing
- Tempering
- Hardening
- Galvanising
- Electroless nickel plating
- Burnishing
- Teniferating
- Others on request
Ensure the integrity of your products with our in-depth testing procedures and comprehensive test reports.
- Evolute and tooth alignment testing
- Partial tooth testing
- Double flank rolling testing
- Initial sample test reports
- Protocols
- Others on request
Customised production solutions according to drawings are created at the headquarters of ZIMM GmbH in Lustenau. Their development, production and documented inspection are part of the ISO 9001:2015 certified processes for customised drive elements such as spur gears, bevel gears, worms, worm gears as well as ball and trapezoidal threads, including the corresponding nuts.
Frequently asked questions about production according to drawing at ZIMM
Submit your inquiry for your manufactured part now
You require gear-cut drive elements, screw drives or ground precision components to your drawing and need a quotation or technical support? Describe your component and attach a drawing, sketch, or specification sheet. Additional information on quantity, required heat treatment or surface treatment and on the test scope needed is helpful. Our application engineers will support you in process selection and production planning, including prototypes and project-specific custom applications.
