| 10 kN | |
| KGT 25×5 | |
| 1500 rpm | |
| 3000 rpm | |
| 13.7kN | |
| 21.5kN | |
| 0.06mm | |
| Aluminium, corrosion-resistant | |
| Steel, case-hardened, ground | |
| 2.1 kg | |
| 2 kg | |
| Synthetic fluid grease | |
| Grease lubrication | |
| max. 60°, higher on request | |
| N: 0.361 kg cm² / L: 0.226 kg cm² | |
| max. 13.5 Nm (N) / max. 7.5 Nm (L) | |
| max. 57 Nm | |
| Translating (S) |
R-Screw | rotating
The spindle is fixed to the worm wheel and rotates with it. The nut therefore moves up and down.
S-Screw | translating
The worm wheel has an internal thread and transforms rotary motion into linear movements as long as the spindle is prevented from rotating.
