250 kN
80×16
1500 rpm
1800 rpm
GGG-50, corrosion-resistant
Steel, case-hardened, ground
62 kg
32 kg
Synthetic fluid oil
Grease lubrication
max. 60°, higher on request
N: 17.71 kg cm² / L: 14.61 kg cm²
max. 152 Nm (N) / max. 41.4 Nm (L)
max. 770 Nm
Translating (S)

Normal Speed Variation Details
TypeZE-250kN-SN
Stroke per drive shaft rotation1.5 mm
Drive ratio10.66:1
Low Speed Variation Details
TypeZE-250kN-SL
Stroke per drive shaft rotation0.50 mm
Drive ratio32:1
