| 100 kN | |
| 60×9 | |
| 1500 rpm | |
| 1800 rpm | |
| Aluminium, corrosion-resistant | |
| Steel, case-hardened, ground | |
| steel | |
| Steel chrome plated | |
| 64.5 kg | |
| 5.6 kg | |
| Synthetic fluid grease | |
| Grease lubrication | |
| max. 60°, higher on request | |
| N: 4.66 kg cm² / L: 3.38 kg cm² | |
| max. 53.4 Nm (N) / max. 13.5 Nm (L) | |
| max. 540 Nm |
Pivot bushes are incorporated in the gearbox housing. Swivel bushes can be subjected to the full nominal load with either compression or tension.
Placement
25kN | Front and rear side
50kN, 100kN, 200kN | Lateral
