| 100 kN | |
| KGT 50×20 | |
| 1500 rpm | |
| 1800 rpm | |
| 127.3kN | |
| 270.3kN | |
| 0.06mm | |
| GGG-50, corrosion-resistant | |
| Steel, case-hardened, ground | |
| 30 kg | |
| 15.7 kg | |
| Synthetic fluid grease | |
| Grease lubrication | |
| max. 60°, higher on request | |
| N: 4.66 kg cm² / L: 3.38 kg cm² | |
| max. 53.4 Nm (N) / max. 13.5 Nm (L) | |
| max. 540 Nm | |
| Translating (S) |
R-Screw | rotating
The spindle is fixed to the worm wheel and rotates with it. The nut therefore moves up and down.
S-Screw | translating
The worm wheel has an internal thread and transforms rotary motion into linear movements as long as the spindle is prevented from rotating.
