YOUR REQUIREMENTS – OUR SOLUTIONS
ZIMM Builder – 3D product configurator for screw jacks, electromechanical actuators and complete lifting systems
The ZIMM Builder is a digital 3D product configurator for ZIMM drive systems with screw jacks, electromechanical actuators and bevel gearboxes. It supports designers in selecting the product series, size, version and suitable add-on parts and provides project-relevant CAD data for further design.
The operator is ZIMM GmbH, headquartered in Lustenau, Austria. The ZA, ZE, ZE-H and GSZ series are fully integrated in the ZIMM Builder; they can be combined with the KSZ-H, KSZ and KST bevel gearboxes, couplings and connecting shafts, motors and motor flanges from the ZIMM modular system. Technical rules, dependencies and exclusion criteria are stored in the system and are automatically taken into account during configuration. For every configuration, 3D and 2D CAD data in STEP, IGES, SAT and DWG formats as well as a 3D PDF for immediate viewing are available; the data is transmitted automatically by email. Access is provided after registration by email, without software installation and completely free of charge.
- Straight to the point | CAD data without detours, without effort
- Design with confidence | Plausibility check in real time
- Flexible customization | Easily combine sizes and accessories
- Better coordination | Share results, speed up approvals
- Simply convincing | Clear, reliable and ready to use at any time
| ZIMM product range | Function in the ZIMM Builder | Technical characteristics | Typical application |
|---|---|---|---|
| Electromechanical actuators (ZA series) | Fully integrated: selection of size, version and add-on parts | 4 sizes: 25 / 50 / 100 / 200 kN · Lifting capacity 25–200 kN per actuator Trapezoidal or ball screw drive ISO 9001:2015 | Lifting · Lowering · Positioning · Adjusting · Supporting · Levelling · Erecting |
| Screw jacks (ZE, ZE-H, GSZ series) | Fully integrated: selection of size, version and add-on parts | 14 sizes: 2.5 / 5 / 10 / 25 / 35 / 50 / 100 / 150 / 200 / 250 / 350 / 500 / 750 / 1,000 kN Lifting capacity 2.5–1,000 kN per gearbox ZE series 5–1,000 kN, ZE-H series 35–350 kN, GSZ series 2.5–150 kN Trapezoidal or ball screw drive ISO 9001:2015 | Lifting · Lowering · Positioning · Adjusting · Supporting · Clamping |
| Bevel gearboxes (KSZ-H, KSZ-2, KST) | Combinable component from the ZIMM modular system | 3 variants Sizes 2.5 kN to 100 kN, matching the screw jack sizes Ratios 1:1 / 2:1 / 3:1Max. 40% duty cycle at 1,500 rpm Backlash-free tapered roller bearing arrangement Same overall height as ZIMM actuators and screw jacks | Drive solutions for limited installation space |
| Connection technology (VWZ, KUZ, KUZ-KK) | Combinable component: couplings and connecting shafts | 24 sizes (VWZ 6, KUZ 12, KUZ-KK 6) Nominal torque up to 660 Nm Elastomer spider Shore 64D, −20 °C to +70 °C, reduced −30 °C to +100 °C KUZ with keyway DIN 6885/1-PP VWZ tested for concentricity from 1,000 mm length | Shafts, couplings and system integration |
| Motor technology (AC three-phase motors, motor flanges) | Combinable component: motors and motor flanges | 4 mounting types (B3, B5, B14B, B14C) Motor power 0.09 kW to 75 kW Motor brake 230 V AC / 205 V DC, other voltages 24 V DC / 400 V AC / 500 V AC on request PTC as standard over 1.5 kW Forced ventilation required for continuous operation below 25 Hz | Motorised solutions in the ZIMM modular system |
| Accessories (ZIMM modular system) | Add-on parts for the selected series | Attachments for electromechanical actuators of the ZA series and screw jacks of the ZE, ZE-H and GSZ series Designs for R-screw (rotating) and S-screw (translating) Fastening, joint, protection, safety and monitoring elements | Customised integration and functional protection |
